Sabra Metals, based in Amman, Jordan, has earned a solid reputation as a reliable supplier of top-notch Aluminium 2017 bars and rods. These high-strength materials are specifically designed for tough industrial and machining tasks. With a focus on consistency, precision, and outstanding customer service, Sabra Metals provides Aluminium 2017 products that are built to withstand stress while ensuring excellent machinability. Thanks to their rigorous quality control and dependable supply chain, the company serves the aerospace, automotive, and engineering sectors throughout the region. Their dedication to reliable service and high material standards makes Sabra Metals a go-to choice for high-performance aluminum alloys.
Aluminium 2017 bars and rods are mainly made from aluminum mixed with copper, along with smaller quantities of magnesium, manganese, and iron. This unique blend gives them impressive strength, great machinability, and solid fatigue resistance. Plus, Aluminium 2017 can be heat-treated to boost its mechanical properties, making it perfect for parts that face moderate to heavy loads. While it may not resist corrosion as well as purer aluminum grades, protective surface treatments can significantly enhance its durability. The alloy strikes a great balance between strength and workability, making it a fantastic option for precision engineering and detailed machining tasks.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2017 | A92017 | 3.1325 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2017 can be welded, but it requires careful control due to its high strength and susceptibility to cracking. Specialized welding techniques like TIG or MIG are recommended.
To maintain Aluminium 2017, regularly clean with mild detergent and water, avoid abrasive materials, store in a dry environment, and prevent exposure to corrosive substances to preserve its strength and appearance.
Aluminium 2017 rods are typically sized by diameter and length. Common diameters range from 1/8 inch to several inches, while lengths can vary from a few feet to custom sizes based on needs.
These Aluminium 2017 bars and rods find their way into a variety of applications that demand strong, lightweight, and easily machinable materials. You’ll often see them in aircraft fittings, rivets, automotive components, gears, fasteners, and high-strength structural parts. They’re also utilized in precision machining, robotics, mechanical systems, and military equipment, where reliable performance and precise dimensions are crucial. Thanks to their excellent chip formation and machinability, Aluminium 2017 is a top choice for crafting intricate parts with tight tolerances. Its strength, fatigue resistance, and versatility make it an invaluable material in advanced manufacturing and engineering fields.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
