Based in Amman, Jordan, Sabra Metals has built a solid reputation as a reliable manufacturer and supplier of top-notch MP35N Bars and Rods, perfect for demanding applications that require high strength and resistance to corrosion. Crafted from a unique nickel–cobalt–chromium–molybdenum alloy, MP35N stands out for its remarkable blend of ultra-high strength, toughness, and resistance to both corrosion and stress corrosion cracking. Sabra Metals takes pride in maintaining strict oversight of chemical composition, processing, and dimensional accuracy to align with international standards. With state-of-the-art manufacturing facilities and dependable supply capabilities, the company caters to industries like aerospace, medical, oil and gas, marine, and high-performance engineering around the globe.
MP35N Bars and Rods are made from a blend of nickel, cobalt, chromium, and molybdenum, resulting in a non-magnetic, corrosion-resistant superalloy. This unique composition allows for significant strengthening through cold working and aging heat treatment. On the mechanical side, MP35N boasts incredibly high tensile and yield strength, excellent fatigue resistance, and remarkable toughness. It maintains stable mechanical properties across a wide temperature range and offers exceptional resistance to stress corrosion cracking, pitting, and crevice corrosion, even in harsh environments.
| Standards : | ASTM F562 / ASME SF562 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Round Bar, Wire |
| Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
|
Cr |
20 nom |
|
Ni |
35 nom |
|
Mo |
10 nom |
|
Co |
35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) | |
| 0..305 | 1.67 | 78 | 0.12 | 0.00000711 | 2510 | |
Yes, MP35N bars can be recycled after use. As a high-performance alloy, it can be melted down and reused to produce new components without significant loss of quality.
MP35N rods are sized based on their diameter and length, typically ranging from 1/16" to 6" diameter and custom lengths, depending on application requirements and manufacturing specifications.
MP35N rods are available in various sizes, typically ranging from 1/8" to 8" in diameter. Common finishes include cold drawn, hot rolled, and annealed for enhanced machinability and surface quality.
MP35N Bars and Rods find their place in a variety of applications that demand ultra-high strength, corrosion resistance, and long-lasting reliability. They are commonly used in medical implants, orthopedic devices, springs, fasteners, shafts, and precision components. Additionally, these materials are extensively utilized in aerospace assemblies, oil and gas downhole equipment, marine hardware, and chemical processing systems. MP35N bars and rods are also ideal for high-performance mechanical components that face cyclic loading, high pressure, and corrosive environments, where any failure is simply not an option.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
