Sabra Metals, located in Amman, Jordan, stands out as a top manufacturer and supplier of premium aluminum products, with a special focus on precision-forged components. Known for their unwavering commitment to quality, the company caters to a variety of industries, including aerospace, automotive, and defense. Sabra Metals is dedicated to providing aluminum forgings that boast exceptional strength, reliability, and durability. With cutting-edge production facilities and rigorous quality control processes, they ensure that every product adheres to international standards. Their deep expertise in materials engineering enables them to create intricate shapes and high-performance components, making Sabra Metals a go-to partner for businesses in need of top-notch Aluminum 2024 forgings.
Aluminum 2024 is a robust alloy primarily made up of aluminum, copper (3.8–4.9%), manganese (0.3–0.9%), and magnesium (1.2–1.8%), along with small amounts of silicon, iron, and zinc. This unique blend provides outstanding fatigue resistance, a high strength-to-weight ratio, and good corrosion resistance when properly treated. The mechanical properties include a tensile strength of about 470–530 MPa, a yield strength of around 325 MPa, and an elongation of 10–20% depending on the temper. Its hardness falls between 120–150 HB. These features make Aluminum 2024 forgings perfect for demanding structural applications where performance and durability are essential.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
Yes, Aluminum 2024 is commonly used in precision forging applications due to its high strength, good fatigue resistance, and excellent machinability, making it suitable for aerospace and high-performance components.
Aluminum 2024 offers high strength, excellent fatigue resistance, good machinability, and superior corrosion resistance, making it ideal for custom forgings in aerospace, military, and high-performance applications.
Aluminum 2024 forgings are extensively used in the aerospace and aviation sectors for parts like aircraft fuselage frames, wings, and landing gear, thanks to their impressive strength and fatigue resistance. They also play a vital role in defense applications, including military vehicles and armor components, where reliability under pressure is key. Beyond aerospace and defense, Aluminum 2024 forgings are found in the automotive and high-performance engineering fields for structural parts and machinery components. Their excellent machinability and strength make them ideal for a wide range of applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
