Nestled in the industrial heart of Amman, Jordan, Sabra Metals has established itself as a trusted partner for high-quality engineered components. Our dedication to precision and excellence shines through in our production of aluminium 5005 forgings. We understand that durable and reliable materials are the backbone of successful projects, which is why we focus on delivering forgings that combine exceptional strength with the signature benefits of aluminium, all backed by our commitment to customer satisfaction and timely delivery.
Aluminium 5005 is known for its excellent balance of properties, forged to enhance its natural strengths. Its composition is primarily aluminium with a small but crucial addition of magnesium, which significantly boosts its strength without sacrificing the metal’s inherent corrosion resistance. The closed-die forging process we employ refines the grain structure, resulting in a component with superior mechanical integrity, including excellent toughness and good fatigue strength, making it a dependable choice for demanding environments.
Standards : ASTM B247, B247
Temper : H34
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Chemical Element | Manganese (Mn) | Iron (Fe) | Copper (Cu) | Magnesium (Mg) | Silicon (Si) | Zinc (Zn) | Chromium (Cr) | Other (Each) | Others (Total) | Aluminium (Al) |
|---|---|---|---|---|---|---|---|---|---|---|
| % Present | 0.0 – 0.20 | 0.0 – 0.70 | 0.0 – 0.20 | 0.50 – 1.10 | 0.0 – 0.30 | 0.0 – 0.25 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Mechanical Property | Tensile Strength | Proof Stress | Hardness Brinell |
|---|---|---|---|
| Value | 145 – 185 MPa | 110 Min MPa | 47 HB |
| European Standard | UNS | GERMANY (DIN) |
| Al-Mg-1 | B57S | A95005 |
Aluminum 5005 offers excellent corrosion resistance, good weldability, formability, and moderate strength, making it ideal for custom forgings in architectural and marine applications, while providing a smooth, aesthetic finish.
Aluminum 5005 is not ideal for high-temperature forging applications. It has moderate strength and good corrosion resistance but lacks the high-temperature stability needed for forging processes.
The versatility of aluminium 5005 forgings makes them ideal for a wide array of demanding roles. You will commonly find these robust components in the marine industry for hardware and fittings, where their resistance to saltwater corrosion is vital. They are equally at home in architectural applications for durable structures, within the transportation sector for critical parts, and across various industrial machinery. Essentially, wherever a combination of moderate strength, light weight, and lasting durability is required, these forgings deliver reliable performance year after year.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
