As a trusted manufacturer and supplier based in Amman, Jordan, Sabra Metals has built a reputation for excellence, particularly with their high-performance Duplex Steel S31803 forgings. We specialize in crafting components that are not only incredibly strong but also exceptionally resistant to corrosion. This makes our products an essential choice for industries operating in the toughest environments, ensuring reliability and longevity where it matters most.
Duplex Steel S31803 is defined by its balanced composition of chromium, nickel, molybdenum, and nitrogen, which gives it a unique dual-phase microstructure. This structure is the secret to its impressive mechanical properties. It offers a remarkable combination of high strength and toughness, along with excellent resistance to stress corrosion cracking, pitting, and crevice corrosion, outperforming many standard stainless steels.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S31803 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel S31803 | 1.4462 | S31803 |
The maximum operating temperature for Duplex Steel S31803 forgings is typically around 300°C (572°F). Beyond this temperature, the material may experience reduced strength and susceptibility to stress corrosion cracking.
Duplex Steel S31803 forgings are available in various sizes, including diameters ranging from 10 mm to 800 mm, and shapes like round, square, billets, blocks, and custom configurations, based on application needs.
Yes, S31803 Duplex Steel forgings are highly resistant to corrosion, especially in chloride-rich environments. They offer excellent protection against pitting, crevice, and stress corrosion cracking, making them ideal for harsh industrial applications.
Because of this unique strength and corrosion resistance, our Duplex Steel S31803 forgings are ideally suited for demanding roles. You’ll frequently find them in offshore and subsea oil & gas equipment, chemical processing plants, and desalination units. They are also essential in the construction of pumps, valves, and high-stress structural components for marine environments, where failure is simply not an option.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
