Based in Amman, Jordan, Sabra Metals is a reliable manufacturer and supplier known for its top-notch Hastelloy C276 Forgings, designed to withstand harsh corrosive and high-temperature conditions. Crafted from a nickel–molybdenum–chromium superalloy, these forgings excel in resisting localized corrosion, stress corrosion cracking, and aggressive chemicals. Sabra Metals takes pride in its meticulous control over the forging process, chemical makeup, and dimensional precision to ensure they meet international quality standards. With state-of-the-art manufacturing facilities and thorough inspection protocols, the company caters to industries like chemical processing, oil and gas, power generation, and heavy engineering around the globe.
Hastelloy C276 Forgings are primarily made of nickel, with notable amounts of molybdenum and chromium, along with carefully controlled levels of iron and tungsten. This unique alloy composition provides exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. On the mechanical side, Hastelloy C276 boasts high tensile strength, impressive ductility, and remarkable toughness. It maintains consistent mechanical properties across a broad temperature range and performs reliably even under extreme thermal and chemical stress.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C276 Forging UNS (N10276), DIN (2.4819)
ISO 9725
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Post-forging operations for Hastelloy C276 include heat treatment (such as annealing) to relieve stresses and improve mechanical properties, followed by surface finishing (like pickling or grinding) to remove oxides and enhance corrosion resistance.
To determine if Hastelloy C276 forgings meet your needs, assess their chemical composition, mechanical properties, and resistance to corrosion under the specific conditions of your application. Conduct testing such as tensile, impact, and corrosion tests for confirmation.
The ideal temperature range for forging Hastelloy C276 is between 1,900°F and 2,200°F (1,038°C to 1,204°C). This ensures proper deformation without compromising material properties.
Hastelloy C276 Forgings find their place in a variety of applications that demand exceptional corrosion resistance and mechanical dependability. They are commonly used in valves, flanges, fittings, heat exchanger components, pressure vessel parts, and pump assemblies. These forgings are extensively utilized in chemical processing plants, petrochemical facilities, oil and gas operations, pollution control systems, and power generation plants. Additionally, Hastelloy C276 forgings are well-suited for handling strong acids, chlorides, and oxidizing agents, where longevity, safety, and performance are of utmost importance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
