Nestled in the industrial heart of Amman, Jordan, Sabra Metals stands as a trusted manufacturer and supplier, dedicated to producing high-performance nickel-alloy components. Our specialization in Incoloy 800HT forgings is a testament to our commitment to quality and resilience. We understand that industries operating under extreme conditions require materials they can depend on, and our forged solutions are engineered to deliver unwavering reliability and durability, meeting the rigorous demands of clients both locally and across international markets.
The strength of Incoloy 800HT lies in its carefully balanced composition, which includes nickel, iron, and chromium, along with additions of titanium and aluminum. This specific formula is heat-treated to achieve exceptional high-temperature performance. The resulting mechanical properties are impressive, offering outstanding tensile and creep-rupture strength, particularly in environments where temperatures can soar. This makes the alloy exceptionally resistant to oxidation and carburization, ensuring long-term structural integrity.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Density | 0.287 lb/in3 / 7.94 g/cm3 |
| Melting Point | 2475 – 2525 °F/ 1357 – 1385 °C |
| Specific Heat @ 70°F | 0.11 Btu/lb•°F |
| Permeability @ 70°F Annealed | 1.014 (200 Oersted) |
| Curie Temperature | -115 °C/ -175 °F |
| Elastic Modulus | 28.50 X 106 psi |
| Electrical Resistivity @ 70°F | 595 ohm•circ mil/ft |
| Annealling Incoloy 800 | 983 – 1038 °C / 1800 – 1900 °F |
| Annealling Incoloy 800H / Ht | 1147 – 1177°C / 2100 – 2150 °F |
| Quench | Rapid Air / Water |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800HT | N08811 | 1.4959 | – | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
To determine if Incoloy 800HT Forgings meet your specific needs, assess their high-temperature resistance, oxidation, and carburization properties against your application requirements. Consulting with a supplier for detailed material specifications and testing options can also ensure compatibility.
The ideal temperature range for forging Incoloy 800HT is between 2100°F (1149°C) and 2300°F (1260°C). This range ensures optimal workability, mechanical properties, and maintains the material's strength and resistance to oxidation.
Temperature control is crucial for maintaining the desired mechanical properties of forged Incoloy 800HT, as overheating or insufficient heating can lead to reduced strength and ductility. Proper temperature management ensures optimal grain structure, resistance to oxidation, and overall performance in high-temperature applications.
These robust forgings are indispensable in sectors where failure is not an option. You will find our Incoloy 800HT components playing a critical role inside ethylene furnace reactors, steam superheaters, and radiant tubes within the petrochemical industry. They are equally vital in nuclear power generation for heat exchangers and in various industrial heating systems. Essentially, wherever intense heat and corrosive atmospheres are a constant challenge, our forgings provide the reliable, long-lasting solution that keeps essential processes running safely and efficiently.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
