Operating from the industrial heart of Amman, Jordan, Sabra Metals has solidified its reputation as a trusted manufacturer and supplier of specialty alloys, with a distinct expertise in Incoloy hollow bars. We recognize that exceptional materials are the cornerstone of demanding industrial projects, and we pride ourselves on delivering not just a product, but a reliable solution engineered for resilience in the most challenging environments that industries face today.
Our Incoloy hollow bars are defined by a sophisticated composition, primarily a nickel-iron-chromium alloy enriched with molybdenum and copper. This unique blend grants them exceptional mechanical properties, including superior tensile strength and impressive yield strength, allowing them to maintain structural integrity under extreme stress. Most notably, they possess an outstanding resistance to corrosion, particularly against acids and localized pitting, making them incredibly durable.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Size of Round Bars | Thickness: 2 milimeter-100 milimeter |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
|---|---|---|---|---|---|---|---|
| Diam. (Inch) | Bar Size | Diam. (mm) | Bar Size | Diameter (mm) | Bar Size | Diameter (mm2) | Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | ||
| 1.375 | #11 | 14 | 14 | 35 | 35 | ||
| 1.500 | #12 | 16 | 16 | 38 | 38 | ||
| 1.625 | #13 | 18 | 18 | 41 | 41 | ||
| 1.750 | #14 | 20 | 20 | 44 | 44 | ||
| 1.875 | #15 | 22 | 22 | 48 | 48 | ||
| 2.000 | #16 | 25 | 25 | 51 | 51 | ||
| 2.250 | #18 | 28 | 28 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
Yes, Incoloy Hollow Bars can be welded using appropriate techniques, such as gas tungsten arc welding (GTAW). Proper welding procedures ensure strong, durable joints with minimal risk of cracking or corrosion.
Incoloy Hollow Bars are highly resistant to corrosion due to their alloy composition, and typically do not require additional coatings. However, in extremely aggressive environments, further protective measures may be considered for enhanced durability.
These remarkable characteristics make Incoloy hollow bars perfectly suited for a wide array of demanding applications. You will typically find them performing reliably in chemical processing equipment, marine components, and pollution control systems where exposure to corrosive media is a constant challenge. They are also the material of choice for constructing heat exchangers, furnace parts, and various components within the oil and gas industry, proving their worth wherever high temperatures and aggressive environments converge.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
