Sabra Metals has established itself as a trusted name in Amman, Jordan, renowned for delivering high-performance nickel alloys to demanding industries. We take pride in our role as a dedicated manufacturer and supplier of Inconel 783 bars and rods, materials engineered for resilience in the most challenging environments. Our commitment lies in providing clients across the region with reliable, high-quality stock that meets precise specifications, supporting the advancement of critical engineering projects with materials built for extreme conditions.
Inconel 783 is a unique superalloy distinguished by its controlled low thermal expansion coefficient, a quality achieved through a specific balance of nickel, cobalt, chromium, and iron, along with additions of aluminum, niobium, and titanium. This sophisticated composition is carefully processed to deliver an excellent combination of high strength and outstanding oxidation resistance. The result is a material that maintains its structural integrity and dimensional stability even when subjected to significant thermal fluctuations and intense heat.
| Dimensions | ASTM, ASME and API |
| Size | 5 mm to 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Grade | Inconel 783 – UNS R30783 |
| Finish | Bright, Polish & Black |
| Length | 100 mm To 3000 mm Long & Above |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | Cu | S | Al | Ti | Ni | Cr |
| Inconel 783 | 0.03 max | 0.05 max | 0.50 max | 0.50 max | 0.05 max | 5-6 | 0.1 – 0.4 | 26-30% | 2.5 – 3.5 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.81 g/cm3 | 1407°C | 1194 MPa | 779 MPa | 24 % |
Density |
7.7-8.03 g/cm3 |
Melting point |
1338-1380 ℃ |
Hardess |
HB335 |
Yes, the exceptional corrosion resistance of Inconel 783 makes it highly suitable for marine environments, where it can withstand saltwater and harsh conditions.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sabrametals.com
Inconel 783 can perform efficiently in environments with temperatures up to 815°C (1500°F), making it suitable for high-temperature industrial and aerospace applications.
The exceptional properties of Inconel 783 bars and rods make them indispensable in aerospace engineering, particularly for components in jet engines like turbine seals and cases where parts must withstand dramatic temperature swings without expanding excessively. Beyond aviation, these materials are crucial in the power generation sector for gas turbine components. They are also increasingly valued in any high-temperature industrial application where lasting durability and reliable performance under thermal stress are non-negotiable for safety and efficiency.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
