From the heart of Amman, Jordan, Sabra Metals has established itself as a trusted source for high-performance nickel alloys, with Monel 400 forgings being a cornerstone of our expertise. We understand that our clients require more than just a product; they need a reliable component built to withstand the most demanding conditions. That’s why we focus on delivering Monel 400 forgings with an unwavering commitment to quality and precision, ensuring they serve as a durable and dependable solution for critical industrial applications both regionally and across the globe.
The exceptional strength of Monel 400 comes from its unique composition, primarily a blend of approximately two-thirds nickel and one-third copper, along with small amounts of iron. This combination gives it remarkable mechanical properties, including high tensile strength and excellent toughness, even in sub-zero temperatures. It maintains its integrity without becoming brittle. Furthermore, it offers good fatigue resistance, allowing it to endure repeated stress cycles, making it a robust material capable of handling significant mechanical demands in harsh environments.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel 400 Forging UNS (N04400), DIN (2.4360)
| Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
| Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
| Density | Melting Range | Curie Temperature | Electricity Resistivity | |||
| g/cm3 | lb/in3 | °F | °C | °F | °C | µΩ·m |
| 8.8 | 0.318 | 2370-2460 | 1300-1350 | 70-120 | 21-49 | 547 |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Temperature control is crucial in forging Monel 400, ensuring optimal mechanical properties, preventing defects, and maintaining its corrosion resistance and strength. Proper control minimizes cracking and enhances overall quality.
Assess Monel 400's forging strength for aerospace by evaluating its tensile strength, yield strength, and fatigue resistance under simulated operating conditions. Conduct tests for thermal stability and corrosion resistance to ensure suitability.
Evaluate Monel 400 forgings by checking their mechanical properties, corrosion resistance, and compatibility with your operating environment. Review certifications, standards, and conduct application-specific testing for assurance.
The unique combination of strength and corrosion resistance makes Monel 400 forgings incredibly versatile. You’ll commonly find them as essential components in marine engineering, such as pump shafts and propeller blades, where they stand up to saltwater corrosion. They are equally vital in the chemical processing industry for crafting valves, fasteners, and reactor parts that handle corrosive substances. Their reliability also makes them a preferred choice for critical applications in oil and gas extraction, as well as in specialized aerospace components, where failure is not an option.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
