Based in Amman, Jordan, Sabra Metals has built a solid reputation as a reliable manufacturer and supplier of top-notch Monel K500 Forgings, perfect for demanding industrial applications that require both strength and resistance to corrosion. Crafted from a nickel–copper alloy that can be precipitation-hardened, these forgings deliver impressive mechanical strength while standing up to harsh seawater and aggressive chemicals. Sabra Metals takes pride in its meticulous control over the forging process, heat treatment, and precision in dimensions to ensure they meet international quality standards. With state-of-the-art manufacturing facilities and thorough inspection protocols, they cater to industries like marine, oil and gas, chemical processing, aerospace, and heavy engineering around the globe.
Monel K500 Forgings are mainly made up of nickel (about 63–70%) and copper, with carefully controlled amounts of aluminum and titanium added to facilitate precipitation hardening. This unique blend results in impressive tensile and yield strength, exceptional fatigue resistance, and enhanced hardness compared to Monel 400. On the mechanical side, Monel K500 boasts remarkable toughness and strong resistance to stress corrosion cracking. It maintains consistent mechanical properties across a wide temperature range, making it an excellent choice for high-load and pressure-bearing forged components.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel K500 Forging UNS (N05500), DIN (2.4375)
BS3072 NA18, QQ-N-286, DIN 17750, ISO 6208
AMS 4676, BS3076 NA18, ASTM B 865, DIN 17752, QQ-N-286, ISO 9723
AMS 4676, ISO 6208, ASTM B 865, DIN 17752, QQ-N-286
BS3076, NA18, DIN 17753, QQ-N-286, ISO 9724
DIN 17754, QQ-N-286, ISO 9725
UNS N05500, BS6076 NA13, Werkstoff Nr. 2.4375, MIL-N-24549, NACE MR-01-75
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
| STANDARD | UNS | WNR. |
| Monel K500 | N05500 | 2.4375 |
Temperature control during the forging of Monel K500 ensures optimal microstructure, improving strength, toughness, and corrosion resistance. It prevents defects like cracking and ensures consistent quality.
To improve the surface finish of forged Monel K500 parts, use techniques like polishing, grinding, or shot peening. Additionally, applying chemical treatments such as pickling can help remove oxides and enhance smoothness.
To determine if Monel K500 forgings meet your needs, evaluate their mechanical properties, corrosion resistance, and compliance with industry standards.
Monel K500 Forgings find their place in a variety of applications that demand high strength, corrosion resistance, and longevity. Common uses include valves, flanges, fittings, pump components, shafts, and parts for pressure vessels. They are heavily utilized in offshore platforms, oil and gas processing equipment, marine engineering, chemical plants, and aerospace systems. Additionally, Monel K500 forgings are ideal for components that face seawater, high pressure, and harsh environments where mechanical reliability and corrosion resistance are absolutely essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
