Situated in the industrial heart of Amman, Jordan, Sabra Metals has built a strong reputation for supplying specialized high-performance alloys to demanding industries. We understand that our clients require materials that can perform under extreme conditions, which is why we take pride in offering RENE 41 bar and rod. This premium solution is specifically chosen for projects where failure is not an option, providing the exceptional strength and temperature resistance needed for the most challenging applications, all supported by our commitment to reliable service and quality assurance.
RENE 41 is a nickel-based superalloy renowned for its ability to maintain integrity in high-stress, high-heat environments. Its composition, which includes significant amounts of chromium, cobalt, and molybdenum, gives it outstanding strength and resistance to corrosion. After a full heat treatment, this material achieves remarkable tensile and creep strength, allowing it to perform reliably at temperatures up to 1800°F (982°C). This makes it a go-to material for engineers designing components that must withstand incredible forces without compromising their structural integrity.
| Standards : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Bar, Rod |
| Tungsten Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
Yes, RENE 41 bar can be welded using suitable techniques like gas tungsten arc welding (TIG) or gas metal arc welding (MIG). Preheating and post-weld heat treatment are recommended for optimal results.
RENE 41 bars are available in sizes ranging from 6mm to 250mm diameter, with finishes including hot-rolled, cold-drawn, rough-turned, centerless ground, and polished options.
Yes, RENE 41 rods are susceptible to galvanic corrosion when coupled with dissimilar metals in an electrolyte, especially if the other metal is more anodic. Proper isolation is recommended.
The exceptional properties of RENE 41 bar and rod make it indispensable in aerospace and industrial gas turbine engines. You’ll find it used in critical components like turbine blades, discs, and afterburner parts where intense heat and rotational forces are a constant challenge. Beyond aviation, its strength and oxidation resistance are leveraged in high-temperature fasteners, sheet metal assemblies for rocket engines, and any application involving severe thermal and mechanical stress. Essentially, it’s the material of choice when you need a component to perform flawlessly under conditions that would cause ordinary metals to fail.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
