Based in Amman, Jordan, Sabra Metals has built a solid reputation as a reliable manufacturer and supplier of high-quality Stainless Steel 17-4 PH Hex Bars and Rods, perfect for high-strength and precision engineering tasks. Crafted from precipitation-hardening martensitic stainless steel, these hex bars offer an impressive mix of strength, corrosion resistance, and dimensional stability. Sabra Metals takes pride in maintaining strict oversight of chemical composition, heat treatment, and hexagonal tolerances to comply with international standards. With state-of-the-art manufacturing facilities and a dependable supply chain, the company caters to industries like aerospace, oil and gas, marine, power generation, and heavy engineering around the globe.
The Stainless Steel 17-4 PH Hex Bars and Rods are made up of chromium (15–17%), nickel (3–5%), copper (3–5%), and niobium, which allows for precipitation hardening through heat treatment. This unique blend results in exceptional tensile and yield strength, along with impressive corrosion resistance. On the mechanical side, SS 17-4 PH boasts excellent toughness, fatigue resistance, and dimensional stability. It reliably maintains its mechanical properties across a wide temperature range, making it an ideal choice for highly stressed structural and mechanical components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 max | 15.00-17.50 max | 3.00-5.00 max | Bal | 1.0 | 3.0-5.0 | 0.40 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-4 PH | 170000 psi | 140000 psi | 6% | 38 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 17-4 PH Hex Bar and Rod should be stored in a dry, clean environment, away from moisture and corrosive substances. Ensure proper ventilation and avoid direct contact with chemicals or humidity.
Yes, Stainless Steel 17-4 PH Hex Bar and Rod can be used for structural applications due to its high strength, excellent corrosion resistance, and ability to withstand extreme environments, making it ideal for demanding conditions.
Common challenges when using Stainless Steel 17-4 PH Hex Bar include difficulties in machining due to its hardness, sensitivity to stress corrosion cracking in certain environments, and the need for precise heat treatment for optimal properties.
Stainless Steel 17-4 PH Hex Bars and Rods find their place in a variety of applications that demand high strength, corrosion resistance, and precision machining. They are commonly used for fasteners, bolts, shafts, valve components, fittings, and structural parts. These hex bars are extensively utilized in aerospace assemblies, oil and gas equipment, marine hardware, power generation systems, and the chemical processing industry. Additionally, SS 17-4 PH hex bars are perfect for high-load mechanical components where fatigue resistance, dimensional accuracy, and a long service life are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
