The strength of Stainless Steel 316 lies in its sophisticated composition, which includes chromium, nickel, and a crucial addition of molybdenum. This alloying blend is what gives the material its outstanding resistance to corrosion, particularly against chlorides and acids. Mechanically, it offers excellent toughness and good ductility, allowing it to be machined into complex parts while maintaining high tensile and yield strength, even in elevated temperature environments, making it a wonderfully robust choice.
Stainless Steel 316 Hex Bars/Rods are composed primarily of iron, with approximately 16-18% chromium, 10-14% nickel, and 2-3% molybdenum, providing excellent corrosion resistance, particularly in chloride environments. The molybdenum enhances resistance to pitting and crevice corrosion. Mechanical properties include high tensile strength (up to 580 MPa), yield strength (up to 290 MPa), and good elongation (40-50%) ensuring durability and flexibility. SS 316 also offers excellent resistance to oxidation and stress-corrosion cracking, making it ideal for demanding applications in chemical processing, oil and gas, and nuclear industries.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 316 Hex Bars/Rods are highly resistant to corrosion, especially in chloride-rich environments like marine settings. Their durability against pitting, crevice corrosion, and stress corrosion cracking makes them ideal for marine and chemical applications. Additionally, their high-temperature resistance and strength enhance performance in harsh conditions.
SS 316 Hex Bars/Rods are commonly used in industries such as marine, chemical processing, pharmaceuticals, food processing, and aerospace. Their superior corrosion resistance protects against rust, pitting, and chemical damage, making them ideal for harsh environments, ensuring longevity, reliability, and reduced maintenance costs in critical applications.
SS 316 Hex Bars/Rods can be easily welded and machined, but precautions are needed. During welding, pre-heating and post-weld heat treatment are recommended to prevent cracking. Use appropriate filler materials for optimal strength. For machining, ensure proper tooling to avoid work hardening and maintain smooth surfaces.
This versatility makes the 316 Hex Bar and Rod indispensable across many fields. In Jordan’s developing industrial and architectural landscape, you’ll find these materials in everything from the fasteners and valves for chemical processing plants to components for desalination equipment and pharmaceutical machinery. Their excellent weldability and formability also make them a favorite for fabricating custom tools, marine hardware, and even architectural features that need to withstand harsh weather, proving their value in both form and function for long-lasting projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
