Nestled in the industrial heart of Amman, Sabra Metals stands as a trusted partner for quality metal supply, bringing reliability and precision to the regional market. We take pride in offering a comprehensive range of materials, with our Stainless Steel 316L Flat Bar exemplifying our commitment to excellence. This particular grade is a cornerstone for demanding applications, renowned for its superior resistance to corrosion and exceptional durability, making it an ideal choice for projects where longevity and performance are absolutely critical.
The strength of 316L lies in its refined composition, which features a low carbon content and a crucial addition of molybdenum. This specific blend enhances its resistance against pitting and corrosion, particularly from chlorides like salt, far surpassing the capabilities of common 304 stainless. Mechanically, it offers excellent tensile strength and good ductility, allowing it to be fabricated and welded with relative ease while maintaining its structural integrity even under stressful conditions, from high temperatures to challenging chemical environments.
Standard : ASTM A276, ASME SA276
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI, ASTM, ASME
Flat Bar Size : 2mm ~ 100mm
Thickness : 1/8″ – 3″
Width : 3/8” – 8”
finish : Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
|---|---|---|---|---|---|---|---|---|---|
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L flat bars primarily consist of 16-18% chromium, 10-14% nickel, and 2-3% molybdenum, with a maximum carbon content of 0.03%. This composition enhances corrosion resistance, especially in chloride-rich environments, making it ideal for demanding applications.
Stainless Steel 316L flat bars are commonly used in industries such as chemical processing, marine, food processing, pharmaceuticals, and petrochemicals. Their high corrosion resistance makes them ideal for applications exposed to aggressive chemicals, saltwater, and high-temperature environments.
The low carbon content in 316L stainless steel reduces carbide precipitation during welding, improving its resistance to intergranular corrosion. This enhances its overall corrosion resistance, particularly in chloride environments, and makes it suitable for applications requiring high strength and durability.
Because of these robust properties, the 316L Flat Bar is indispensable across a diverse spectrum of industries. You’ll find it forming the backbone of structures in coastal architecture, serving as essential components in chemical processing plants, and meeting the stringent hygiene standards of pharmaceutical and food production equipment. Its versatility also extends to marine hardware, surgical instruments, and architectural detailing, proving its value anywhere strength and resistance to harsh elements are non-negotiable for long-term success.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
