For manufacturers and engineers in Amman and beyond, Sabra Metals stands as a reliable partner for high-quality metal components. We take pride in supplying precision-engineered materials like the Stainless Steel 416 Hollow Bar, offering a perfect blend of durability and machinability for the region’s demanding industrial applications. Our commitment is to provide not just a product, but a dependable solution that supports the growth and precision of your projects, right from the heart of Jordan’s industrial landscape.
The standout feature of Stainless Steel 416 is its exceptional free-machining quality, thanks to added sulfur, which makes it a favorite for high-speed automated equipment. This martensitic grade also offers a good balance of strength and corrosion resistance, capable of being heat-treated to achieve higher mechanical properties. It’s a practical choice when you need a material that allows for fast production times without sacrificing the essential robustness required for durable components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Range : Range – 3.17mm to 350mm dia
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| Hollow Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
SS 416 hollow bars are commonly used in industries like automotive, aerospace, and petrochemicals, as well as in manufacturing pumps, valves, and gears due to their machinability and corrosion resistance.
SS 416 hollow bars are not ideal for high-temperature applications due to their reduced corrosion resistance and mechanical properties at elevated temperatures. They perform best in moderate conditions, excelling in machinability and wear resistance for general engineering uses.
This hollow bar is incredibly versatile, finding its place in a wide array of essential components. You’ll often find it machined into everyday items like shafts, valves, and pump parts, where its smooth machinability keeps production efficient. Its reliability also makes it suitable for more demanding roles in the automotive and aerospace industries, such as in nuts and bolts, where consistent performance is non-negotiable. Essentially, it’s the go-to material for parts that must be produced quickly and perform reliably under pressure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
