Sabra Metals stands out as a reliable manufacturer and supplier based in Amman, Jordan, focusing on high-quality Titanium Grade 1 Forgings. These forgings are perfect for industries that need outstanding corrosion resistance, ductility, and reliability. With a reputation for precision engineering and a strong commitment to international quality standards, Sabra Metals delivers titanium forgings that consistently excel in tough industrial settings. Their Titanium Grade 1 Forgings not only offer excellent formability but also boast superior chemical stability, making them a top choice for critical applications. Thanks to their advanced production technology and dedication to quality, Sabra Metals ensures that their titanium solutions are dependable for both local and global markets.
When it comes to Titanium Grade 1 Forgings, they are crafted from commercially pure titanium with very few alloying elements, which gives them the best corrosion resistance among commercially pure titanium grades. These forgings are known for their excellent ductility, good tensile strength, and impressive impact toughness, along with outstanding weldability and formability. They effectively resist pitting, crevice corrosion, and stress-corrosion cracking while maintaining stability across a wide range of temperatures. Grade 1 titanium forgings are perfect for applications that require both lightweight performance and long-lasting reliability in challenging environments.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | O | N | Fe | H | Ti | I |
| Min | – | – | – | – | – | 99.095 | – |
| max | 0.080 | 0.18 | 0.030 | 0.2 | 0.015 | 100 | 0.2 |
| Grades | Tensile KSI Min | Yield KSI Min/Max | % Elongation Min |
| Titanium Gr 1 | 35 | 25/45 | 24 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 1 | 3.7025 | R50250 |
Titanium Grade 1 forgings are commonly used in aerospace, chemical processing, marine, medical, and automotive industries due to their excellent corrosion resistance, lightweight, high strength, and biocompatibility properties.
Titanium Grade 1 forgings are made by heating titanium billets, then shaping them using compressive forces like hammering or pressing, followed by precision machining to achieve the desired specifications.
Open-die forging for Titanium Gr 1 involves compressing heated titanium between flat or contoured dies, allowing metal to deform freely, producing strong, customized components with excellent structural integrity.
You’ll find Titanium Grade 1 Forgings used across various industries where corrosion resistance, formability, and durability are crucial. They’re commonly found in chemical processing equipment, heat exchangers, desalination systems, and marine components that come into contact with seawater or harsh chemicals. Their biocompatibility also makes them a great fit for medical implants and surgical instruments. In aerospace and environmental engineering, these forgings are utilized for structural components, piping systems, and equipment where lightweight and reliable corrosion-resistant materials are essential. Grade 1 titanium forgings are designed to deliver long-term performance even in demanding operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
