Sabra Metals stands out as a top manufacturer and supplier based in Amman, Jordan, specializing in high-quality Titanium Grade 1 Bars and Rods. These products are crafted for industries that demand exceptional purity, corrosion resistance, and reliability. With a strong focus on precision and adherence to international quality standards, Sabra Metals guarantees that each product performs consistently, even in the toughest environments. Their Titanium Grade 1 Bars and Rods are particularly appreciated for being lightweight, easily formable, and capable of enduring various atmospheric and marine conditions. Thanks to their advanced manufacturing processes and dedicated customer support, Sabra Metals is committed to delivering reliable titanium solutions to both local and global markets.
Titanium Grade 1 Bars and Rods are made from commercially pure titanium with very few alloying elements, making them the softest and most ductile option among titanium grades. They boast excellent corrosion resistance in both oxidizing and mildly reducing environments, along with impressive impact toughness and superior weldability. In terms of mechanics, they offer moderate tensile strength, low density, and remarkable formability, which allows for easy fabrication into intricate shapes. Their stable performance across a wide temperature range, coupled with strong resistance to seawater and chemicals, makes them ideal for a variety of industrial applications.
| Standards : | ASTM B348, B863 / ASME SB 348, SB 863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 1 | 3.7025 | R50250 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | 0.08 max | 0.03 max | 0.18 max | 0.015 max | Bal | 0.20 20 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 240 | 170 | 24 % |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51Â g/cc | 0.163Â lb/inÂł |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 1 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sabrametals.com
These Titanium Grade 1 Bars and Rods are extensively used in sectors that require lightweight, corrosion-resistant, and easily formable materials. They’re commonly found in chemical processing equipment, marine components, desalination systems, and heat exchangers, thanks to their excellent resistance to seawater and corrosive substances. Their biocompatibility also makes them perfect for medical implants and surgical instruments. In the aerospace industry, they are utilized for structural components where reducing weight while maintaining durability is crucial. Additionally, they play a vital role in power generation, automotive parts, and environmental engineering, ensuring long-term reliability across various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
