Sabra Metals, based in Amman, Jordan, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Tool and Die Steel D2 bars, catering to a variety of industrial sectors throughout the region. The company is well-regarded for its unwavering commitment to quality, precision, and dependability, providing materials that are specifically designed to handle the rigors of machining, forming, and cutting tasks. By blending cutting-edge processing techniques with rigorous quality controls, Sabra Metals ensures that its D2 steel bars meet international standards. Their strong reputation stems from consistent performance, timely deliveries, and excellent technical support, making them a go-to partner for toolmakers, fabricators, and manufacturers in search of durable, high-performance steel solutions.
Tool and Die Steel D2 bars are known for their high carbon content (around 1.40–1.60%) and notable chromium levels (approximately 11–13%), along with trace amounts of molybdenum, vanadium, and manganese. This unique blend gives D2 steel remarkable wear resistance and hardness. It boasts impressive compressive strength, good dimensional stability during heat treatment, and strong abrasion resistance. After proper treatment, D2 can achieve hardness levels of about 58–62 HRC, making it exceptionally durable for heavy-duty tooling while still offering moderate toughness and edge retention.
| ASTM A681 | C | Mn | P | S | Si | Cr | V | Mo | ||||||
| D2 | 1.4 | 1.6 | 0.1 | 0.6 | 0.03 | 0.03 | 0.1 | 0.6 | 11 | 13 | 0.5 | 1.1 | 0.7 | 1.2 |
| DIN ISO 4957 | C | Mn | P | S | Si | Cr | V | Mo | ||||||
| 1.2379/X153CrMo12 | 1.45 | 1.6 | 0.2 | 0.6 | 0.03 | 0.03 | 0.15 | 1.6 | 11 | 13 | 0.7 | 1 | 0.7 | 1 |
| JIS G4404 | C | Mn | P | S | Si | Cr | V | Mo | ||||||
| SKD11 | 1.4 | 1.6 | 0.6 | 0.03 | 0.03 | 0.4 | 11 | 13 | 0.2 | 0.5 | 0.8 | 1.2 | ||
| Mechanical Properties | Metric | Imperial |
| Hardness, Knoop (converted from Rockwell C hardness) | 769 | 769 |
| Hardness, Rockwell C | 62 | 62 |
| Hardness, Vickers | 748 | 748 |
| Izod impact unnotched | 77.0 J | 56.8 ft-lb |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elastic modulus | 190-210 GPa | 27557-30457 ksi |
| Country | USA | German | Japan |
| Standard | ASTM A681 | DIN EN ISO 4957 | JIS G4404 |
| Grades | D2 | 1.2379/X153CrMo12 | SKD11 |
| Properties | Conditions | ||
| T (°C) | Treatment | ||
| Thermal expansion | 10.4 x 10-6/ºC | 20-100 | – |
Tool and Die Steel D2 Bars can be welded, but it's challenging due to their high carbon content. Preheating, post-weld heat treatment, and using specific filler materials are essential.
Tool and Die Steel D2 Bars are semi-corrosion-resistant due to high chromium content (12%). While not fully stainless, they offer moderate resistance to rust in less aggressive environments.
These D2 bars find extensive use in industries that require components capable of withstanding repeated impacts, abrasion, and high stress. They are commonly used to manufacture cutting tools, shear blades, blanking and punching dies, forming dies, and embossing tools. Thanks to its hardness and wear resistance, D2 is perfect for long-run production tooling where maintaining dimensional accuracy is essential. It’s also employed in industrial knives, gauges, molds, and precision tooling for both plastics and metalworking. Across sectors like automotive, fabrication, and general engineering, D2 steel bars consistently deliver reliable performance, extended tool life, and dependable output, even under the most demanding operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
